Donno Bikes Mod

It's not just a cargo bike. It's your Donno Bikes.

IN GIFT:

GPS anti-theft device with DonnoSafe

GPS anti-theft device with DonnoSafe

10-year warranty

Because trust is measured over time

DonnoSafe GPS anti-theft system

Your bike, always under control

Documents for legal use

Ready to transport passengers and goods, in order.

Premium support in over 70 cities

Your personal mechanic, always close to you.

Platinum Club Donno Bikes

More than a bike. A world of exclusive advantages.

Leave the car keys at home and get in the saddle with the family!

The Yuba Kombi E5 is a compact pedal-assisted cargo longtail bicycle, Yuba's most popular electric model. Ideal for city dwellers who want to try the cargo adventure, choosing to use a bicycle to replace their car, but with a smooth ride! The Yuba Kombi E5 boasts a number of unique features.

High-quality components. Shimano components give it high performance at a competitive price. Powered by a Shimano STePS E5000 mid-drive motor and a 418 Wh battery, it can easily accompany you on any city route. It will surprise you with its robustness and manoeuvrability. It rides with style and its hydraulic disc brakes help instil confidence when you stop under load. The 9-speed system allows you to choose from a wide range of gears according to the terrain and load on board.

Adapts to your needs. The chassis of the Yuba Kombi E5 can easily be customised for you. Children, adults, side bags... endless possibilities await you! You can put 2 child seats for the little ones, protective poles for the big ones and a cover for rainy days. Everything is possible with the Kombi E5! You will probably drive it more than you use your car!

La The Yuba Kombi e5 embodies our vision of advanced cycling, combining power and versatility in a design that adapts to urban needs, just like a bicycle with a structure foldable e power-bike.

Informazioni dettagliate

Traction system
Motor Shimano STePS E5000 250W 36V
Permitted speed EU 25km/h, USA 20-28mph
Battery Shimano 418Wh
Autonomy 70-100 km
Frame
Type Long tail pedal-assisted cargo bike
Frame Kombi V1 chrome-molybdenum alloy Cr-Mo 1-1/8"
Model Unisex, for cyclists from 152cm to 193cm
Dimensions 189 x 64 x 106cm
Weight 29kg
Passengers 4 including cyclist
Maximum flow rate 200kg including rider
Wheels
Circles Alloy
Rays 36H
Tyres Maxxis Hookworm 24" x 2.5"
Transmission
Change Shimano Altus SGS Trigger Shifter
Front derailleur N/A
Rear derailleur Shimano RD-M2000
Speed 9 speed
Chain KMC E9
Sprocket pack Shimano 11-36T 9-Speed
Crankset and crank Shimano FC-E5010 170mm
Pedals Vp-527 Aluminium
Brakes
Front brake Shimano Alivio hydraulic disc brake
Rear brake Shimano Alivio hydraulic disc brake
Rotors Shimano 180mm front, 180mm rear
Levers Shimano Alivio
Components
Saddle Yuba City
Seatpost Aluminium 31.6mm, 400mm
Handlebar 31.8mm City, 1-1/8" adjustable attachment
Knobs Velo Ergo
Roof rack length 785mm
Included as standard Bell, double kickstand, LED light kit, mudguards, stabiliser spring
Features
Country of production United States
Warranty 2 years

suitable for cyclists from 152cm to 193cm tall

maximum load capacity 200kg (rider + cargo)

Please note that when added together, the individual load ratings given for the rider and load will exceed the total maximum load capacity. Therefore, although it is possible to maximise the individual load ratings selected by redistributing the weight, the sum of all loads must never exceed the certified maximum load capacity (rider+load ≤ 200kg/440lb).

The lightest and quietest system

Shimano STePS E5000

Torque/Power : 80Nm/250W

Maximum speed : EU 25km/h, USA 28mph, NZ/CH 45km/h

Battery : Shimano 418W/h Ioni di litio

Autonomy : 70-90km

Weight : 2.4kg

276
60
60
95
102
180
238
238
24
70
155
48
276
36
24
60
47

*Specifications are subject to change without notice. In case of unexpected supply-side impacts, we will offer components of equivalent or better capabilities.

One bike. A thousand uses

Discover all the configurations of the YUBA KOMBI E5 DonnoBikes Mod, designed to perfectly suit your lifestyle

Use YUBA KOMBI E5 DonnoBikes Mod

Without accessories it looks like a normal e-bike, but its agility, load capacity and vertical parking possibility make it unique.

Use YUBA KOMBI E5 DonnoBikes Mod

A 70 cm rack to which large side bags can be attached and a shopping bag in the front basket make it an ideal substitute for the car.

Use YUBA KOMBI E5 DonnoBikes Mod

Compatible with Yepp, Qibbel and most child seats available on the market. The cargo bike is designed to carry two children safely.

Use YUBA KOMBI E5 DonnoBikes Mod

Carry one child in one seat and a second older child in the back. Safety poles are optional but absolutely recommended.

Use YUBA KOMBI E5 DonnoBikes Mod

Carry a child on the seat and two side bags. Even without the front basket, the load capacity is considerable.

Use YUBA KOMBI E5 DonnoBikes Mod

Safely carry two older children. The safety bars are designed to support, protect and entertain your children.

Use YUBA KOMBI E5 DonnoBikes Mod

Carries one or two adult passengers. Side rails and handles to choose from ensure comfort and secure hold during the ride.

Use YUBA KOMBI E5 DonnoBikes Mod

Use the cargo bike in all weather conditions, protecting your cargo. Your passengers will always have a panoramic view.

So, what do you do?
Do you keep thinking about it or do you get in the saddle?

Excellent service.

I would like a custom-made YUBA KOMBI E5 DonnoBikes Mod

Your bike, the way you want it.
From the saddle to the fork, every detail is built according to your needs and preferences.
Because every family is unique, and your cargo bike can be too.

[ Choose a ready-made configuration ]

I would like a YUBA KOMBI E5 DonnoBikes Mod standard

We have already selected the ideal configurations for most families. We have tested them. More than 1000 families in Italy have approved them.
They are ready to go. And maybe you too.

Video

Scopri tutte le configurazioni della YUBA KOMBI E5 DonnoBikes Mod, pensate per adattarsi perfettamente al tuo stile di vita

Donno Bikes Youtube Video YUBA KOMBI E5 DonnoBikes Mod

Lifestyle with Kombi E5

Discover how this cargo e-bike can change your daily routine

Donno Bikes Youtube Video YUBA KOMBI E5 DonnoBikes Mod

Presentation of Kombi E5

A 360* view of Yuba's new electric cargo model

Donno Bikes Youtube Video YUBA KOMBI E5 DonnoBikes Mod

Introduction to the characteristics

Presentation of the main technical and design functions

Donno Bikes Youtube Video YUBA KOMBI E5 DonnoBikes Mod

Kombi E5 from the Donno Bikes workshop

Learn about display, brakes, gearbox, Shimano motor and settling in

Donno Bikes Youtube Video YUBA KOMBI E5 DonnoBikes Mod Yuba Kombi E5

Yuba E5 an e-bike to carry up to 200kg
