YUBA SPICY CURRY

YUBA SPICY CURRY - TECHNICAL SPECIFICATIONS

Traction system
Motor Bosch Cargo Line 250W 36V
Permitted speed EU 25km/h, USA 20-28mph
Battery Bosch Powerpack 500 36V
Autonomy 70-90 km
Control display Kiox
Frame
Type Long tail pedal-assisted cargo bike
Frame Spciy Curry Aluminium 6061-T6
Model Unisex, for cyclists from 152cm to 195cm
Dimensions 210 x 68 x 115cm
Weight 27.3kg
Passengers 4 including cyclist
Maximum flow rate 200kg including rider
Wheels
Circles DB-32 MTB
Rays 36H
Tyres Schwalbe Super Moto X 26" x 2.4" front, 20" x 2.4" rear
Transmission
Change Shimano Deore SL-M6000 Trigger Shifter
Front derailleur N/A
Rear derailleur Shimano Deore RD-M6000
Speed 10 speeds
Chain KMC X10e 10-Speed
Sprocket pack Shimano 11-36T 10-Speed
Crankset and crank Lasco 170mm 50T
Pedals VP-501 alloy
Brakes
Front brake Magura MT32 Hydraulic
Rear brake Magura MT32 Hydraulic
Rotors Magura Storm HC 180mm
Levers Magura MT32 Hydraulic
Components
Saddle Yuba Comfort
Seatpost Aluminium 30.9mm, 400mm
Handlebar 31.8mm City, adjustable stem 1.5" 100mm
Knobs Yuba Ergo with alloy connection
Roof rack 950mm
Included as standard Bell, AXA light kit, mudguards, stabiliser spring
Features
Country of production United States
Warranty 2 years

Specifications are subject to change

The intelligent system from an industry leader

Cargo Line

Torque/Power 85Nm/250W

Support level : 400%

Maximum speed EU 25km/h, USA 28mph, NZ/CH 45km/h

Battery : Power Pack 500W/h Lithium-ion

Autonomy 80-120km

Weight 2.9kg

suitable for cyclists from 152cm to 195cm tall

maximum load capacity 200kg (rider + cargo)

Please note that when added together, the individual load ratings given for the rider and load will exceed the total maximum load capacity. Therefore, although it is possible to maximise the individual load ratings selected by redistributing the weight, the sum of all loads must never exceed the certified maximum load capacity (rider+load ≤ 200kg/440lb).

276
60
60
95
102
238
238
24
336
70
155
144
276
36
24
60
